Stainless Steel Pipes Manufacturer, Supplier, Exporter, and Stockist in India- Sachin Steel Centre
Apex Steel Centre is one of the Largest Stainless Steel Pipes Manufacturer in India. We have been an essential part of the growth and development of the Indian market and quality exports. We manufacture ASTM A312 Stainless Steel Pipe in various sizes and shapes and with different specifications per our valuable clients' requirements. Stainless Steel Pipes have very high corrosion resistance and are becoming more cost-effective frequently. Our Supplied SS Pipes are known for their reliability and quality worldwide.
Stainless Steel Pipes And Tubes Specification
| Product |
Stainless Steel Pipes & Tubes |
| Standards |
ASTM A312, ASTM A213, ASTM A269, ASTM A270, ASTM A554, ASTM A249 |
| Grades |
TP304, TP304L, TP304/304L, TP310S, TP316, TP316L, TP316/316L, TP317L, TP321, TP347H, S31803, 904L |
| Type |
Seamless, Welded, Fabricated |
| NB Size |
1/2″ to 48″, Thickness: SCH 5S, 10S, 40S (STD), 80S (XS), 160, XXS |
| OD Size |
O. D. : Φ 6 to Φ 406mm, W.T: 1 mm to 30 mm |
| Specification |
ASTM, ASME, DIN |
| Finish |
Annealed & Pickled, 2B, No.4, Mirror, Polish |
Chemical Properties of Stainless Steel Pipes
| A312 GRADES |
UNS |
C |
Mn |
P |
S |
Si |
Cr |
Ni |
Mo |
Ti |
Nb |
N |
| TP304 |
S30400 |
0.08 |
2 |
0.045 |
0.03 |
1 |
18.0-20.0 |
8.0-11.0 |
|
|
|
|
| TP304L |
S30403 |
0.035 |
2 |
0.045 |
0.03 |
1 |
18.0-20.0 |
8.0-13.0 |
|
|
|
|
| TP304H |
S30409 |
0.04-0.10 |
2 |
0.045 |
0.03 |
1 |
18.0-20.0 |
8.0-11.0 |
|
|
|
|
| TP304N |
S30451 |
0.08 |
2 |
0.045 |
0.03 |
1 |
18.0-20.0 |
8.0-18.0 |
|
|
|
0.10-0.16 |
| TP304LN |
S30453 |
0.035 |
2 |
0.045 |
0.03 |
1 |
18.0-20.0 |
8.0-12.0 |
|
|
|
0.10-0.16 |
| TP309S |
S30908 |
0.08 |
2 |
0.045 |
0.03 |
1 |
22.0-24.0 |
12.0-15.0 |
0.75 |
|
|
|
| TP309H |
S30909 |
0.04-0.10 |
2 |
0.045 |
0.03 |
1 |
22.0-24.0 |
12.0-15.0 |
|
|
|
|
| TP309Cb |
S30940 |
0.08 |
2 |
0.045 |
0.03 |
1 |
22.0-24.0 |
12.0-16.0 |
0.75 |
|
10xC min |
|
| 1.10 max |
| TP309HCb |
S30941 |
0.04-0.10 |
2 |
0.045 |
0.03 |
1 |
22.0-24.0 |
12.0-16.0 |
0.75 |
|
10xC min |
|
| 1.10 max |
| TP310S |
S3108 |
0.08 |
2 |
0.045 |
0.03 |
1 |
24.0-26.0 |
19.0-22.0 |
0.75 |
|
|
|
| TP310H |
S3109 |
0.04-0.10 |
2 |
0.045 |
0.03 |
1 |
24.0-26.0 |
19.0-22.0 |
|
|
|
|
| TP310Cb |
S31040 |
0.08 |
2 |
0.045 |
0.03 |
1 |
24.0-26.0 |
19.0-22.0 |
0.75 |
|
10xC min |
|
| 1.10 max |
| TP310HCb |
S31041 |
0.04-0.10 |
2 |
0.045 |
0.03 |
1 |
24.0-26.0 |
19.0-22.0 |
0.75 |
|
10xC min |
|
| 1.10 max |
| TP316 |
S3160 |
0.08 |
2 |
0.045 |
0.03 |
1 |
16.0-18.0 |
11.0-14.0 |
2.0-3.0 |
|
|
|
| TP316L |
S31603 |
0.035 |
2 |
0.045 |
0.03 |
1 |
16.0-18.0 |
10.0-14.0 |
2.0-3.0 |
|
|
|
| TP316H |
S31609 |
0.04-0.10 |
2 |
0.045 |
0.03 |
1 |
16.0-18.0 |
11.0-14.0 |
2.0-3.0 |
|
|
|
| TP316Ti |
S31635 |
0.08 |
2 |
0.045 |
0.03 |
0.75 |
16.0-18.0 |
10.0-14.0 |
2.0-3.0 |
5x |
|
0.1 |
| (C-N) |
| -0.7 |
| TP316N |
S31651 |
0.08 |
2 |
0.045 |
0.03 |
1 |
16.0-18.0 |
10.0-14.0 |
2.0-3.0 |
|
|
0.10-0.16 |
| TP316LN |
S31653 |
0.035 |
2 |
0.045 |
0.03 |
1 |
16.0-18.0 |
11.0-14.0 |
2.0-3.0 |
|
|
0.10-0.16 |
| TP317 |
S3170 |
0.08 |
2 |
0.045 |
0.03 |
1 |
18.0-20.0 |
10.0-14.0 |
3.0-4.0 |
|
|
|
| TP317L |
S31703 |
0.035 |
2 |
0.045 |
0.03 |
1 |
18.0-20.0 |
11.0-15.0 |
3.0-4.0 |
|
|
|
| TP321 |
S3210 |
0.08 |
2 |
0.045 |
0.03 |
1 |
17.0-19.0 |
9.0-12.0 |
|
|
|
0.1 |
| TP321H |
S32109 |
0.04-0.10 |
2 |
0.045 |
0.03 |
1 |
17.0-19.0 |
9.0-12.0 |
|
|
|
0.1 |
| TP347 |
S3470 |
0.08 |
2 |
0.045 |
0.03 |
1 |
17.0-19.0 |
9.0-13.0 |
|
|
|
|
| TP347H |
S34709 |
0.04-0.10 |
2 |
0.045 |
0.03 |
1 |
17.0-19.0 |
9.0-13.0 |
|
|
|
|
| TP347LN |
S34751 |
0.05-0.02 |
2 |
0.045 |
0.03 |
1 |
17.0-19.0 |
9.0-13.0 |
|
|
0.20- |
0.06-0.10 |
| 50 |
| TP348 |
S3480 |
0.08 |
2 |
0.045 |
0.03 |
1 |
17.0-19.0 |
9.0-13.0 |
|
|
|
|
| TP348H |
S34809 |
0.04-0.10 |
2 |
0.045 |
0.03 |
1 |
17.0-19.0 |
9.0-13.0 |
|
|
|
|
Mechanical Properties of Stainless Steel Pipes
| ASTM A312 Mechanical Properties |
| Material |
Heat |
Temperure |
Tensile Strength |
Yield Strength |
Elongation %, Min |
| Treatment |
Min. |
Ksi (MPa), Min. |
Ksi (MPa), Min. |
| |
º F(º C) |
|
|
| TP304 |
Solution |
1900 (1040) |
75(515) |
30(205) |
35 |
| TP304L |
Solution |
1900 (1040) |
70(485) |
25(170) |
35 |
| TP304H |
Solution |
1900 (1040) |
75(515) |
30(205) |
35 |
| TP310S |
Solution |
1900 (1040) |
75(515) |
30(205) |
35 |
| TP316 |
Solution |
1900(1040) |
75(515) |
30(205) |
35 |
| TP316L |
Solution |
1900(1040) |
70(485) |
25(170) |
35 |
| TP316H |
Solution |
1900(1040) |
75(515) |
30(205) |
35 |
| TP316Ti |
Solution |
1900(1040) |
75(515) |
30(205) |
35 |
| TP321 |
Solution |
1900(1040) |
75(515) |
30(205) |
35 |
| TP321H |
Solution |
Cold: 2000(1100) |
75(515) |
30(205) |
35 |
| Hot: 1925(1050) |
| TP347 |
Solution |
1900(1040) |
75(515) |
30(205) |
35 |
| TP347H |
Solution |
Cold: 2000(1100) |
75(515) |
30(205) |
|
| Hot: 1925(1050) |
|
